Nissan Maxima A33 (1999-2006) 38 11 22 ign ppl Wiring diagrams

38 11 22 IGN PPL BAT POWER WINDOW RAP POWER WINDOW BAT GND GND 53 54 49 52 BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (NEAR FUSE BLOCK (J/B)) DN UP DOWN UP ENCODER POWER DOWN PULSE FULL STROKE FULL STROKE FUSE 1 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK F GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START ILLUMINATION LEFT FRONT DOOR KEY CYLINDER SWITCH PPL LEFT FRONT POWER WINDOW MOTOR (AT CENTER OF LEFT FRONT DOOR) LEFT REAR POWER WINDOW SWITCH LIMIT SW LIMIT SWITCH LOCK LOCK SWITCH UNLOCK SWITCH MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH POWER WINDOW SERIAL LINK PPL RAP RED WIRE RIGHT REAR SWITCH UNLOCK SW LOCK SW UP DN UP DN UNLOCK LEFT REAR SWITCH LOCK SWITCH UP DOWN ENCODER WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE

38 11 22 IGN PPL BAT POWER WINDOW RAP POWER WINDOW BAT GND GND 53 54 49 52 BETWEEN FULL STROKE, N BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (NEAR FUSE BLOCK (J/B)) DOWN ENCODER ENCODER POWER ENCODER POWER DOWN PULSE FULL STROKE FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE 1 FUSE, FUSIBLE FUSIBLE LINK F LINK BOX (AT LEFT FRONT OF ENGINE COMPT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START ILLUMINATION LEFT FRONT DOOR KEY CYLINDER SWITCH LEFT FRONT POWER WINDOW MOTOR (AT CENTER OF LEFT FRONT DOOR) LIMIT SW LIMIT SWITCH LOCK SW LOCK SWITCH MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH PNK/BLU WIRE POWER WINDOW SERIAL LINK PPL PULSE RAP RED WIRE RIGHT FRONT POWER WINDOW MOTOR (AT CENTER OF RIGHT FRONT DOOR) RIGHT FRONT POWER WINDOW SWITCH UNLOCK SW UNLOCK SWITCH UP ENCODER WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
