Nissan Maxima A33 (1999-2006) 21 22 29 30 batt ign gnd gnd Wiring diagrams
This page contains all the electrical diagrams for the component. 21 22 29 30 batt ign gnd gnd, in which he is found in the car Nissan Maxima A33 (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 21 22 29 30 batt ign gnd gnd (1 of 2)
19 9 11 1 RX TX CAN-L CAN-H
21 22 29 30 BATT IGN GND GND
ABS CONTROL UNIT
ABS IND.
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN/YEL WIRE
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DIAG-K FL (-)
FL (+) CAN-L FR (+)
FL IN SOL
FL OUT SOL
FR (-)
FR IN SOL
FR OUT SOL
FUSE 12
FUSE 14
FUSE 19
FUSE 20
FUSE 49
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK G
FUSIBLE LINK H
G SENSOR
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IPDM E/R (AT RIGHT FRONT OF ENGINE COMPT)
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
LT GRN WIRE
MOTOR BATT
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RL (+)
RL IN SOL
RL OUT SOL
RR (+) IGN GND MOT (+) MOT (-)
RR (-)
RR IN SOL
RR OUT SOL
SOL BATT GND BRL
SOLENOID VALVE
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
UNIFIED METER CONTROL UNIT
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH)
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit, without traction control -> 21 22 29 30 BATT IGN GND GND
Wiring diagram 21 22 29 30 batt ign gnd gnd (2 of 2)
19 9 11 1 RX TX CAN-L CAN-H
21 22 29 30 BATT IGN GND GND
ABS IND.
ABS/TCS CONTROL UNIT
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN/YEL WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DIAG-K FL (-)
FL (+) CAN-L FR (+)
FL IN SOL
FL OUT SOL
FR (-)
FR IN SOL
FR OUT SOL
FUSE 12
FUSE 14
FUSE 19
FUSE 20
FUSE 49
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (AT LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK G
FUSIBLE LINK H
G SENSOR
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IPDM E/R (AT RIGHT FRONT OF ENGINE COMPT)
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
LT BLU WIRE
LT GRN WIRE
MOTOR BATT
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RL (+)
RL IN SOL
RL OUT SOL
RR (+) IGN GND MOT (+) MOT (-)
RR (-)
RR IN SOL
RR OUT SOL
SLIP IND
SOL BATT GND BRL
SOLENOID VALVE
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
TCS OFF SW CAN-H
TCS ON/OFF SWITCH
UNIFIED METER CONTROL UNIT
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH)
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit, with traction control -> 21 22 29 30 BATT IGN GND GND
