Nissan Maxima A32 (1994-2000) supplemental restraints Wiring diagram
This page shows the only wiring diagram for the component.supplemental restraints, which is found in the car Nissan Maxima A32 (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram supplemental restraints (1 of 1)
ABS IND.
AIRBAG IND
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR)
BRAKE IND
BRN/WHT WIRE
BRN/YEL WIRE
CHARGE IND
COMBINATION METER
CRUISE CONTROL
CRUISE CONTROL, BODY COMPUTER
CRUISE IND
DOOR IND
DRIVER SEAT BELT BUCKLE SWITCH
ECCS CONTROL MODULE (ECM) (BELOW CENTER OF DASH)
FLEXIBLE PRINT CIRCUIT
FUEL GAUGE
FUEL IND
FUEL TANK GAUGE UNIT (IN TANK)
FUSE 13
FUSE 18
FUSE 40
FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEADLIGHT SYSTEM (CANADA)
HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN PARK OR HEAD
INTERIOR LIGHTS SYSTEM ANTI-LOCK BRAKES SYSTEM
JOINT CONNECTOR 10 (IN JUNCTION BOX)
LEFT TURN IND
LT GRN/BLK WIRE
LT PNK WIRE
MALFUNCTION IND
METER ILLUM
O/D OFF IND
ODO/TRIP METER ILLUM
ODOMETER/TRIP METER
OIL IND
OIL PRESSURE SWITCH (LOWER RIGHT FRONT SIDE OF ENGINE)
ORG/ WIRE
ORG/BLU WIRE
PARKING BRAKE SWITCH (AT BASE OF OF PARK BRAKE LEVER)
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT TURN IND
SEAT BELT IND
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS
TACHOMETER
THERMAL TRANSMITTER (LEFT REAR OF ENGINE)
TRANSMISSION CONTROL MODULE (TCM) (AT FRONT OF CENTER CONSOLE)
UNIFIED METER CONTROL UNIT
VEHICLE SPEED SENSOR (ON TRANSAXLE)
WASHER IND
WASHER LEVEL SWITCH (IN FLUID RESERVOIR)
WATER TEMP GAUGE
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Instrument cluster circuit -> SUPPLEMENTAL RESTRAINTS
