Nissan Maxima A32 (1994-2000) left trunk lid combination lamp Wiring diagrams
This page contains all the electrical diagrams for the component. left trunk lid combination lamp, in which he is found in the car Nissan Maxima A32 (1994-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left trunk lid combination lamp (1 of 2)
Go to component -> Back-up lamps circuit -> LEFT TRUNK LID COMBINATION LAMP
Wiring diagram left trunk lid combination lamp (2 of 2)
BLK WIRE
BLU WIRE
FUSE 10
FUSE 5
FUSE 66
FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
J/C 7 (WHITE) (IN RELAY BOX 1)
LEFT FRONT SIDE MARKER LAMP LEFT PARK- ING LAMP
LEFT TRUNK LID COMBINATION LAMP
LIGHT SWITCH
NCA WIRE
OFF
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT SIDE MARKER LAMP
RIGHT PARK- ING LAMP
RIGHT TRUNK LID COMBINATION LAMP
STOP
STOP LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
STOP TAIL
TAIL
W/ SPOILER
W/O SPOILER
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LEFT TRUNK LID COMBINATION LAMP
