Nissan Maxima A32 (1994-2000) fuse 12 Wiring diagrams

1 4 8 13 16 LINE A-1 LOCK SW STEP LAMP BAT GND 1 8 13 16 LINE A-2 STEP LAMP BAT GND BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (UNDER FRONT OF CENTER CONSOLE) CIRCUIT BREAKER 2 (BEHIND DASH, ABOVE FUSE BLOCK) DIODE (LEFT SIDE OF TRUNK) DOOR DRIVER DOOR CONTROL UNIT (IN DRIVER'S DOOR) FUSE 12 FUSE 26 FUSE 40 FUSE 56 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK F GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START INTERIOR LAMP LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT STEP LAMP LEFT VANITY MIRROR ON OFF PASSENGER DOOR CONTROL UNIT (IN PASSENGER'S DOOR) PNK WIRE PNK/GRN WIRE PPL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR SWITCH LEFT FRONT DOOR SWITCH RIGHT FRONT STEP LAMP RIGHT REAR DOOR SWITCH LEFT REAR DOOR SWITCH RIGHT VANITY MIRROR SPOT LAMP TRUNK ROOM LAMP TRUNK ROOM LAMP SWITCH (CENTER OF TRUNK LID) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE

2 4 VEHICLE SPEED INPUT AIR VALVE SOLENOID ANTI-THEFT SYSTEM ASCD BRAKE SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) ASCD CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) ASCD HOLD RELAY (IN RELAY BOX 2) ASCD PUMP (LEFT REAR OF ENGINE COMPARTMENT) ASCD STEERING SWITCH ASCD SWITCH BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE BRN/YEL WIRE CRUISE INDICATOR CRUISE SIGNAL OD CUT SIGNAL ENGINE CONTROLS SYSTEM (VSS) FUSE 10 FUSE 12 FUSE 17 FUSE 64 FUSE AND FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT) FUSE BLOCK (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HORN RELAY (IN RELAY BOX 2) HORN SYSTEM HOT AT ALL TIMES HOT IN ON OR START ILLUM INHIBITOR RELAY (IN RELAY BOX 2) INHIBITOR SWITCH (ON LEFT REAR SIDE OF TRANSAXLE) INSTRUMENT CLUSTER INTERIOR LIGHTS LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE NCA WIRE OD CANCEL SIG CRUISE LAMP RELEASE VALVE TK (HCC) RX (HCC) OFF ON IND. PNK WIRE PNK/BLU WIRE PNK/GRN WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELEASE VALVE SOLENOID RESUME/ ACCELERATE SET/COAST SPIRAL CABLE STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) SYSTEM THEFT WARNING RELAY (IN RELAY BOX 1) (WITH ANTI- THEFT) TRANSMISSION CONTROL MODULE (BELOW CENTER CONSOLE, FORWARD OF SHIFT LEVER) VACUUM MOTOR VEHICLE SPEED OUTPUT WHT/RED WIRE YEL WIRE

2 4 VSS INPUT AIR VALVE SOLENOID ASCD BRAKE SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) ASCD CLUTCH SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL) ASCD CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) ASCD HOLD RELAY (IN RELAY BOX 2) ASCD PUMP (LEFT REAR OF ENGINE COMPARTMENT) ASCD STEERING SWITCH ASCD SWITCH BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE BRN/YEL WIRE CRUISE INDICATOR CRUISE LAMP RELEASE VALVE TK (HCC) RX (HCC) FUSE 10 FUSE 12 FUSE 64 FUSE AND FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT) FUSE BLOCK (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HORN RELAY (IN RELAY BOX 2) HORN SYSTEM HOT AT ALL TIMES HOT IN ON OR START ILLUM INSTRUMENT CLUSTER INTERIOR LIGHTS LT GRN WIRE LT GRN/BLK WIRE NCA WIRE OFF ON IND. PNK WIRE PNK/BLU WIRE PNK/GRN WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELEASE VALVE SOLENOID RESUME/ ACCELERATE SET/COAST SPIRAL CABLE STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) SYSTEM VACUUM MOTOR VEHICLE SPEED OUTPUT VEHICLE SPEED SENSOR (ON TRANSAXLE) WHT/RED WIRE YEL WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) (UNDER FRONT OF CENTER CONSOLE) CONDENSER (LEFT "C" PILLAR) DOOR MIRROR DEFOGGER RELAY (BEHIND RIGHT KICK PANEL) DRIVER SIDE DOOR MIRROR DEFOGGER FUSE 12 FUSE 38 FUSE 39 FUSE 7 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START PASSENGER SIDE DOOR MIRROR DEFOGGER PPL REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY (IN RELAY BOX 1) REAR WINDOW DEFOGGER SWITCH RED WIRE YEL WIRE

ALTERNATOR BLK WIRE BLU WIRE BRN/WHT WIRE DAYTIME LIGHT CONTROL UNIT (RIGHT FRONT OF ENGINE COMPT) FRONT FOG LAMP RELAY (IN RELAY BOX 1, RIGHT SIDE OF ENGINE COMPT) FRONT LEFT FOG LAMP FRONT RIGHT FOG LAMP FUSE 12 FUSE 33 FUSE 53 FUSE 54 FUSE 63 FUSE BLOCK (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN HOT IN ON OR START INSTRU- MENT CLUSTER HI BEAM IND INSTRUMENT CLUSTER SYSTEM J/C 5 (IN RELAY BOX 1, RIGHT SIDE OF ENGINE COMPT) J/C 6 (IN RELAY BOX 1, RIGHT SIDE OF ENGINE COMPT) LEFT HEADLAMP LIGHTING SWITCH LOW HI LT FRONT FOG LAMP SWITCH LT GRN WIRE LT GRN/BLK WIRE OFF ORG/ WIRE ORG/BLK WIRE PARKING BRAKE SWITCH PASS PASS LOW HI RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT HEADLAMP THEFT WARNING LAMP RELAY (IN RELAY BOX 1, RIGHT SIDE OF ENGINE COMPT) WHT WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLU WIRE CIRCUIT BREAKER 2 (BEHIND DASH, ABOVE FUSE BLOCK) CLOSE DOWN FUSE 12 FUSE BLOCK GRN WIRE HOT AT ALL TIMES HOT IN ON OR START NCA WIRE OPEN SLIDE SWITCH RED WIRE RED/GRN WIRE SUNROOF MOTOR ASSEMBLY (AT FRONT OF SUNROOF OPENING) SUNROOF RELAY (BEHIND LEFT KICK PANEL) SUNROOF SWITCH TILT SWITCH WHT WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

12 11 DOWN UP 17 1 12 BAT 17 2 12 BAT 27 1 11 12 3 IG BAT DATA LINE A-2 DATA LINE A-1 GRD PNK WIRE BAT GRD BCM (BODY CONTROL MODULE) (UNDER FRONT OF CENTER CONSOLE) BLK WIRE BLU/BLK WIRE BLU/RED WIRE CIRCUIT BREAKER 2 (BEHIND DASH, ABOVE FUSE BLOCK) D/AUTO LEFT FRONT FUSE FUSE 12 FUSE 56 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPARTMENT) GRD GRN WIRE HOT AT ALL TIMES HOT IN ON OR START ILLUM LEFT FRONT POWER WINDOW REGULATOR LEFT REAR LEFT REAR DOOR CONTROL UNIT LEFT REAR POWER WINDOW REGULATOR (IN LEFT REAR DOOR) LOCK LOCK SW PASSENGER DOOR CONTROL UNIT PNK WIRE PNK/GRN WIRE POWER LEFT REAR POWER WINDOW MAIN SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT RIGHT FRONT POWER WINDOW REGULATOR (IN PASSENGER'S DOOR) RIGHT REAR RIGHT REAR DOOR CONTROL UNIT (IN RIGHT REAR DOOR) RIGHT REAR POWER WINDOW REGULATOR (IN RIGHT REAR DOOR) RIGHT REAR POWER WINDOW SUB- SWITCH UNLOCK WHT WIRE WHT/RED WIRE WINDOW SUB- WINDOW SUB- RIGHT POWER

ASCD BRAKE SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) BLK WIRE BLU WIRE CRUISE CONTROL SYSTEM FUSE 12 FUSE BLOCK (BEHIND LEFT SIDE OF DASH) HOT IN ON, START LT GRN/RED WIRE PARK POSITION SWITCH (BELOW FRONT CONSOLE) PNK/GRN WIRE SHIFT LOCK SOLENOID (BELOW FRONT CONSOLE) WHT WIRE
