Nissan Maxima A32 (1994-2000) engine control module (under center console) wiring diagram
This page shows the only wiring diagram for the component.engine control module (under center console), which is found in the car Nissan Maxima A32 (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
engine control module (under center console) wiring diagram (1 of 1)
ACRLY
AIR CONDITIONER
ARCON
BLK WIRE
BLK/RED WIRE
COMPRESSOR)
COOLING FAN MOTOR 1
COOLING FAN MOTOR 2
COOLING FAN RELAY 1 (RELAY BOX 1, LEFT FRONT OF ENGINE COMPT)
COOLING FAN RELAY 2
COOLING FAN RELAY 3
ENGINE CONTROL MODULE (UNDER CENTER CONSOLE)
FUSE 17
FUSE AND FUSIBLE LINK BOX
FUSE BLOCK
FUSIBLE LINK D FUSE 61
FUSIBLE LINK E
GRN/BLK WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON AND START
IACV-FICD SOLENOID VALVE
J/C 1 (LEFT FRONT OF ENG COMPT)
J/C 2 (LEFT FRONT OF ENG COMPT)
J/C 3 (LEFT FRONT OF ENG COMPT)
J/C 7 (RIGHT SIDE OF ENG COMPT)
LT GRN WIRE
LT GRN/RED WIRE
PNK WIRE
RELAY (RELAY BOX 2, RIGHT FRONT OF ENGINE COMPT)
RFRH
RFRL
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> A/c circuit, auto a/c (2 of 2) -> ENGINE CONTROL MODULE (UNDER CENTER CONSOLE)
