Nissan Maxima A32 (1994-2000) driver side air bag module Wiring diagram
This page shows the only wiring diagram for the component.driver side air bag module, which is found in the car Nissan Maxima A32 (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side air bag module (1 of 1)
1 2 DATA LINK CONNECTOR (BEHIND LEFT SIDE OF DASH) PNK WIRE
AIR BAG DIAGNOSIS SENSOR UNIT (BELOW REAR OF CENTER CONSOLE)
AIR BAG IND
BLK WIRE
BLU WIRE
BRN/YEL WIRE
COMBINATION METER
DOOR
DRIVER AIR BAG MODULE
DRIVER SIDE AIR BAG MODULE
DRIVER SIDE SATELLITE SENSOR
FUSE 1
FUSE 13
FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
GRN WIRE
HOT IN ON OR START
LED
NCA WIRE
ORG/ WIRE
PASSENGER AIR BAG MODULE
PASSENGER SIDE AIR BAG MODULE
PASSENGER SIDE SATELLITE SENSOR
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RX TX PNK WIRE
SPIRAL CABLE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit -> DRIVER SIDE AIR BAG MODULE
