Nissan Maxima A32 (1994-2000) cruise control system Wiring diagrams
This page contains all the electrical diagrams for the component. cruise control system, in which he is found in the car Nissan Maxima A32 (1994-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cruise control system (1 of 3)
AIR CONDITIONING SYSTEM
AIR CONDITIONING, ENGINE CONTROLS SYSTEMS
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CELLULAR PHONES SYSTEM DEFOGGER SYSTEM
CRUISE CONTROL SYSTEM
CRUISE CONTROL, HEADLIGHTS SYSTEM
DEFOGGER SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, ANTI-THEFT SYSTEMS
ENGINE CONTROLS, TRANSMISSIONS ANTI-LOCK BRAKES SYSTEMS TRANSMISSIONS SYSTEMS
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
EXTERIOR LIGHTS SYSTEMS
EXTERIOR LIGHTS, TRANSMISSIONS SYSTEMS
FROM FUSE 11 (DIAGRAM 2 OF 2)
FROM FUSIBLE LINK K (DIAGRAM 1 OF 2)
FROM IGNITION RELAY (DIAGRAM 2 OF 2)
FROM IGNITION SWITCH (DIAGRAM 1 OF 2)
FUSE 1
FUSE 10
FUSE 11
FUSE 13
FUSE 14 FUSE 28 FUSE 12
FUSE 15
FUSE 16
FUSE 17 FUSE 4
FUSE 22
FUSE 24 FUSE 40
FUSE 26
FUSE 29
FUSE 32
FUSE 34
FUSE 37
FUSE 38
FUSE 39
FUSE BLOCK (J/B)
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HORNS, WARNING, ANTI-THEFT SYSTEMS CELLULAR PHONES SYSTEMS
IGNITION RELAY
INSTRUMENT CLUSTER SYSTEM
INTEGRATED HOMELINK TRANSMITTER (CENTER FRONT OF ROOF)
LT GRN WIRE
MULTI-REMOTE CONTROL UNIT, POWER ANTENNA, ANTI-THEFT SYSTEMS
ORG/BLU WIRE
PNK (W/ AUTO A/C) WIRE
PNK WIRE
PNK/ GRN WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/GRN WIRE
POWER TOPS SYSTEM
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SEATS SYSTEM
SOUND SYSTEM
SOUND SYSTEM DOOR LOCKS, INTERIOR LIGHTS, WARNING SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
TO FUSE 1 (DIAGRAM 2 OF 2)
TO IGNITION RELAY (DIAGRAM 2 OF 2)
TRANSMISSIONS SYSTEMS
TRANSMISSIONS, EXTERIOR LIGHTS, CRUISE CONTROL, ANTI-LOCK BRAKES SYSTEMS
TRUNK, TAILGATE, FUEL DOOR RELEASE SYSTEM
W/O AUTO A/C
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (2 of 2) -> CRUISE CONTROL SYSTEM
Wiring diagram cruise control system (2 of 3)
Go to component -> Shift interlock circuit -> CRUISE CONTROL SYSTEM
Wiring diagram cruise control system (3 of 3)
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BELOW CENTER OF DASH)
CRUISE CONTROL SYSTEM
FUSE 17
FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK H
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
IGNITION SWITCH
INHIBITOR RELAY (IN RELAY BOX 2, LEFT FRONT CORNER OF ENGINE COMPT)
INHIBITOR SWITCH (ON LEFT REAR SIDE OF
NCA WIRE
OFF
RED WIRE
STARTER INTER- RUPT
STARTER MOTOR
THEFT WARNING RELAY (IN RELAY BOX 1, RIGHT SIDE OF ENGINE COMPT)
TRANSAXLE
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
WHT/PNK WIRE
Go to component -> Starting circuit, a/t -> CRUISE CONTROL SYSTEM
