Nissan Maxima A32 (1994-2000) 29 30 28 cnslt data clk cnslt data out cnslt data in pnk Wiring diagram
This page shows the only wiring diagram for the component.29 30 28 cnslt data clk cnslt data out cnslt data in pnk, which is found in the car Nissan Maxima A32 (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 29 30 28 cnslt data clk cnslt data out cnslt data in pnk (1 of 1)
18 46 16 RXD TXD DIAGL PNK WIRE
20 21 SSS RX SSS TX PNK WIRE
29 30 28 CNSLT DATA CLK CNSLT DATA OUT CNSLT DATA IN PNK WIRE
78 76 75 69 SCICL SCITX SCIRX KLINE PNK WIRE
ABS CONTROL UNIT (BEHIND LEFT KICK PANEL)
AIR BAG DIAGNOSIS SENSOR UNIT (BELOW REAR OF CENTER CONSOLE)
BLK WIRE
BLU WIRE
BRN/YEL WIRE
DATA LINK CONNECTOR (FOR CONSULT) (BEHIND LEFT SIDE OF DASH)
DATA LINK CONNECTOR (FOR GST) (BEHIND LEFT SIDE OF DASH)
ECCS CONTROL MODULE (ECM) (BELOW CENTER OF DASH)
FUSE 17
FUSE 40
FUSE BLOCK
GRN/BLK WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
RED WIRE
RED/YEL WIRE
TOP OF ENGINE)
TRANSMISSION CONTROL MODULE (BELOW CENTER CONSOLE, FORWARD OF SHIFT LEVER)
YEL WIRE
Go to component -> Computer data lines -> 29 30 28 CNSLT DATA CLK CNSLT DATA OUT CNSLT DATA IN PNK WIRE
