Nissan Leaf II (2017-2024) w/ propilot assist wiring diagram
This page shows the only wiring diagram for the component.w/ propilot assist, which is found in the car Nissan Leaf II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/ propilot assist wiring diagram (1 of 1)
ADAS CONTROL UNIT (RIGHT SIDE OF DASH)
AEB OFF
ASCD STEERING SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER SIG
BUZZER SIG GND
CANCEL SWITCH
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
DISTANCE SWITCH
DRIVER ASSISTANCE BUZZER
FUSE 13
FUSE 38
FUSE 4
FUSE 5
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSIBLE LINK J
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IC CAN H
IC CAN L
ICC MAIN ON/OFF SWITCH (W/ ICC) PROPILOT MAIN ON/OFF SWITCH
IGN
IND
ITS CAN-H PNK ITS CAN-L WIRE
LT BLU WIRE
LT GRN WIRE
MAIN (ON/OFF) SWITCH
MOTOR
NAVIGATION SYSTEM
PNK WIRE
PPL
PPL BRK-RLY PPL SW SIG
PPL/BRN WIRE
PPL/WHT WIRE
RED WIRE
RES/+ SWITCH
SET SWITCH
SIG
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
V CAN-H
V CAN-L
VDC OFF
W/ ICC, PROPILOT
W/ PROPILOT ASSIST
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (1 of 2) -> W/ PROPILOT ASSIST
