Nissan Leaf II (2017-2024) w/ navigation, 8 inch colour display w/o navigation, w/ 8 inch colour display Wiring diagram
This page shows the only wiring diagram for the component.w/ navigation, 8 inch colour display w/o navigation, w/ 8 inch colour display, which is found in the car Nissan Leaf II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ navigation, 8 inch colour display w/o navigation, w/ 8 inch colour display (1 of 1)
A/C AUTO AMP
APPROACHING VEHICLE SOUND FOR PEDESTRIANS (VSP) CONTROL UNIT
AV CONTROL UNIT
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN TERMINATOR (ITS CAN COMMUNICATION)
CAN TERMINATOR 1 (ITS CAN COMMUNICATION)
CAN TERMINATOR 2 (ITS CAN COMMUNICATION)
CAN-H
CHASSIS CONTROL MODULE
DISTANCE SENSOR (ICC SENSOR)
EV CAN-H
EV CAN-L
EV SYSTEM CAN-H
EV SYSTEM CAN-L
GRN WIRE
GRY WIRE
IC CAN H
IC CAN L
ITS CAN-H
ITS CAN-L
LI-ION BATTERY LI-ION BATTERY CONTROLLER
LT BLU WIRE
PNK WIRE
PPL
RED WIRE
SONAR CONTROL UNIT
V CAN-H
V CAN-L
VCM
W/ NAVIGATION, 8 INCH COLOUR DISPLAY W/O NAVIGATION, W/ 8 INCH COLOUR DISPLAY
W/O ELECTRIC PARKING BRAKE
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (2 of 3) -> W/ NAVIGATION, 8 INCH COLOUR DISPLAY W/O NAVIGATION, W/ 8 INCH COLOUR DISPLAY
