Nissan Leaf II (2017-2024) meter control switch Wiring diagrams
This page contains all the electrical diagrams for the component. meter control switch, in which he is found in the car Nissan Leaf II (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram meter control switch (1 of 2)
BLK WIRE
BLU WIRE
CHARGE PORT LID OPENER SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR MIRROR REMOTE CONTROL SWITCH
E-PEDAL SWITCH
ECO MODE SWITCH
FUSE 5
FUSE BLOCK (J/B)
GRY WIRE
HEATED STEERING WHEEL SWITCH
HOT W/ IGNITION RELAY-2 ENERGIZED
ILLUMINATION CONTROL SWITCH DOWN
ILLUMINATION CONTROL SWITCH UP
IMMEDIATE CHARGING SWITCH
LT BLU WIRE
METER CONTROL SWITCH
METER ILLUMINATION
PNK WIRE
PPL
PPL PNK WIRE
PPL/BLK WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/WHT WIRE
RED WIRE
TELEMATICS SWITCH
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> METER CONTROL SWITCH
