Nissan Leaf II (2017-2024) input 2 ppl/pnk input 1 Wiring diagram
This page shows the only wiring diagram for the component.input 2 ppl/pnk input 1, which is found in the car Nissan Leaf II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram input 2 ppl/pnk input 1 (1 of 1)
BAT FUSE
BCM (BODY CONTROL MODULE) (RIGHT SIDE OF DASH)
BELT IND
BLK WIRE
BLU WIRE
BRAKE IND
BUZZER
CAN L
CAN-H
COMBI SW INPUT 1
COMBI SW INPUT 2
COMBI SW INPUT 3
COMBI SW INPUT 4
COMBI SW INPUT 5
COMBI SW OUTPUT 1
COMBI SW OUTPUT 2
COMBI SW OUTPUT 3
COMBI SW OUTPUT 4
COMBI SW OUTPUT 5
COMBINATION METER
COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH)
COMPUTER DATA LINES SYSTEM
DOOR SW (DR)
FUSE 13
FUSE 5
FUSE 9
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
INPUT 2 PPL/PNK INPUT 1 WIRE
INPUT 3
INPUT 4
INTELLIGENT KEY WARNING BUZZER
LEFT FRONT DOOR SWITCH
LEFT SEAT BELT BUCKLE SWITCH
LT BLU WIRE
OUTPUT 2 PPL OUTPUT 1 INPUT 5
OUTPUT 3
OUTPUT 4
OUTPUT 5
PARKING BRAKE SWITCH
PNK WIRE
PPL
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT GRN WIRE
PPL/PNK WIRE
PPL/TAN WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RED WIRE
SMART KEYLESS BUZZER OUTPUT
TAN WIRE
UNIFIED METER CONTROL UNIT
W/ DRIVER POWER SEAT
WHT WIRE
YEL WIRE
Go to component -> Chime circuit -> INPUT 2 PPL/PNK INPUT 1 WIRE
