Nissan Leaf II (2017-2024) eps ind Wiring diagram
This page shows the only wiring diagram for the component.eps ind, which is found in the car Nissan Leaf II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eps ind (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
BATTERY
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
EPS CONTROL UNIT (LEFT SIDE OF DASH)
EPS IND
EPS MOTOR
FUSE 13
FUSE 3
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSIBLE LINK N
GND 2 (PWR)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
LT GRN WIRE
NCA WIRE
PNK CAN-L WIRE
PNK WIRE
POSITION SIG
PPL/WHT WIRE
RED WIRE
STEERING ANGLE SENSOR
TORQUE MAIN SENS SIG
TORQUE SENS GND
TORQUE SENS PWR SPLY
TORQUE SENS REF VOLT
TORQUE SENSOR
TORQUE SUB SENS SIG
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) COMBINATION METER
V IGN
VCM
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> EPS IND
