Nissan Leaf II (2017-2024) dlk backup pwr wiring diagram
This page shows the only wiring diagram for the component.dlk backup pwr, which is found in the car Nissan Leaf II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
dlk backup pwr wiring diagram (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/ORG WIRE
BLU/YEL WIRE
BRAKE COMMUNICATION-H
BRAKE COMMUNICATION-L
BRAKE POWER SUPPLY BACKUP UNIT
BRN WIRE
BUZZER PWR
BUZZER SIGNAL
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
DLC COMMUNICATION
DLC WAKE-UP
DLK BACKUP PWR
ECU CONTROL SYSTEM PWR
ELECTRICALLY DRIVEN INTELLIGENT BRAKE UNIT
FUSE 31
FUSE 62
FUSE 75
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSE, FUSIBLE LINK, RELAY BOX 2
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK F
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
MOTOR PWR
PPL
PWR SWITCH ON
RED WIRE
SHIELD
STOP LAMP SW
STROKE SENSOR
STROKE SENSOR 1 SIGNAL
STROKE SENSOR 2 SIGNAL
STROKE SENSOR GND
STROKE SENSOR PWR
TAN WIRE
WARNING BUZZER
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (3 of 3) -> DLK BACKUP PWR
