Nissan Leaf II (2017-2024) charge connector lock relay Wiring diagrams
This page contains all the electrical diagrams for the component. charge connector lock relay, in which he is found in the car Nissan Leaf II (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram charge connector lock relay (1 of 2)
A/C AUTO AMP
AUDIO UNIT
AV CONTROL UNIT
BLK WIRE
BLU WIRE
CHARGE CONNECTOR LOCK RELAY
CHARGE PORT LID OPENER SWITCH
COMBINATION SWITCH (SPIRAL CABLE)
DOOR MIRROR REMOTE CONTROL SWITCH
E-PEDAL SWITCH
ECO MODE SWITCH
ELECTRIC PARKING BRAKE SWITCH
F/S RELAY
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 6)
FRONT FOG LAMP RELAY
FRONT WIPER RELAY
FUSE 43
FUSE 45
FUSE 46
FUSE 47
FUSE 64
GLOVE BOX LAMP)
GRN WIRE
GRY WIRE
HAZARD SWITCH
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HEATED STEERING WHEEL SWITCH
IMMEDIATE CHARGING SWITCH
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT FET HIGH
LEFT FRONT COMBINATION LAMP
LEFT FRONT HEATED SEAT SWITCH
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LT BLU WIRE
LT GRN WIRE
MAP LAMP (MOOD LAMP)
METER CONTROL SWITCH
PNK WIRE
PPL
PPL/BLU WIRE
PPL/WHT WIRE
REAR HEATED SEAT SWITCH
RED WIRE
RIGHT FET HIGH
RIGHT FRONT COMBINATION LAMP
RIGHT FRONT HEATED SEAT SWITCH
RIGHT FRONT SEAT HEATER
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
SELECTOR INDICATOR
STEERING ASSIST SWITCH
STEERING WHEEL AUDIO CONTROL SWITCHES
TAIL LAMP RELAY
TAN WIRE
TEL/ICC STEERING SWITCH
TELEMATICS SWITCH
TO IGNITION RELAY-1 (DIAGRAM 4 OF 6)
W/ NAVIGATION, 8 INCH COLOR DISPLAY
W/O NAVIGATION, 8 INCH COLOR DISPLAY
WHT WIRE
Go to component -> Power distribution circuit (3 of 6) -> CHARGE CONNECTOR LOCK RELAY
Wiring diagram charge connector lock relay (2 of 2)
