Car Wiring Diagrams for Starting circuit for Nissan Kicks I facelift (2020-2024)

BATTERY BCM (BODY CONTROL MODULE) BLK/RED WIRE BLU WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 42 FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK E FUSIBLE LINK M GRN WIRE GRY WIRE HOT AT ALL TIMES IGNITION RELAY 1 INTELLIGENT KEY UNIT IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT BLU WIRE PNK WIRE PNP SIG PUSH BUTTON IGNITION SWITCH PUSH SWITCH RED WIRE RIGHT END OF DASH) START SW STARTER CUT RELAY STARTER MOTOR STARTER RELAY STARTER RL TAN WIRE TOP OF TRANSMISSION) TRANSMISSION RANGE SWITCH WHT WIRE
