Premium radio circuit, w/ bose for Nissan Kicks I facelift (2020-2024)

AV CONTROL UNIT (CENTER OF DASH) BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE CAMERA COMP + CAMERA SHIELD CAN L CAN-H COMPUTER DATA LINES SYSTEM FRONT AUXILIARY INPUT JACKS FUSE 12 FUSE 18 FUSE 21 FUSE 29 FUSE 36 FUSE BLOCK (J/B) GRN WIRE HF/VR MIC 1 INPUT HF/VR MODE CHANGE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED ILL INTERIOR LIGHTS LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MIC GND MIC IN - (GND) MIC MODE CHANGE MIC SIG MIC VCC MICROPHONE (IN ROOF CONSOLE) NAVIGATION SYSTEM NAVIGATION SYSTEM (TELEMATICS CIRCUIT) PNK WIRE PPL PWR STOP LAMPS RED WIRE SHIELD SYSTEM TAN WIRE TCU TEL IN- TCU TEL SHIELD V-BUS W/ TELEMATICS SYSTEM W/O TELEMATICS SYSTEM WHT WIRE

AMP ON ANT MAIN ANT SHIELD ANTENNA (B+) ANTENNA AMP AV CONTROL UNIT (CENTER OF DASH) BACK BASE ANTENNA BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY BACK DISPLAY FWD FR SP LH (-) FR SP RH (-) GRN WIRE IGN LT BLU WIRE LT GRN WIRE MENU DOWN MENU OK MENU UP NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NCA WIRE PNK WIRE PPL PREAMP SHIELD RED WIRE REVERSE RR SP LH (-) RR SP RH (-) SAT ANT SAT ANT SHIELD SATELLITE ANTENNA SEEK DOWN SEEK UP SHIELD STEERING SWITCHES TAN WIRE TEL ON UNIFIED METER CONTROL UNIT VBUS VOLUME DOWN UP VOLUME- WHT WIRE YEL WIRE

AMP ON BLK WIRE BLU WIRE BOSE SPEAKER AMPLIFIER BRN WIRE DR HRST SP LH+ DR HRST SP RH- DRIVER SEAT HEADREST SPEAKER FR DR WOOFER/TWEETER LH- FR DR WOOFER/TWEETER RH- FR LH GRN WIRE GRY WIRE LEFT FRONT DOOR SPEAKER LEFT FRONT TWEETER LEFT REAR DOOR SPEAKER LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT REAR DOOR SPEAKER RR DOOR LH - RR DOOR RH - RR LH+ RR RH+ SHIELD WHT WIRE YEL WIRE
