Car Wiring Diagrams for Rear view camera circuit for Nissan Kicks I facelift (2020-2024)

AUDIO UNIT AV CONTROL UNIT (CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE CAMERA GND CAMERA V + FUSE 36 FUSE BLOCK (J/B) GRY WIRE HOT AT ALL TIMES LT GRN WIRE PNK W/O NAVIGATION WIRE PNK WIRE PPL/RED WIRE PPL/WHT WIRE REAR VIEW CAMERA RV POWER GND RV VIDEO GND RV VIDEO SIGNAL SHIELD SHIELD CAMERA SHIELD PNK CAMERA COMP+ WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE
