Car Wiring Diagrams for Courtesy lamps circuit for Nissan Kicks I (2016-2020)

AS DOOR SW BACK DOOR LOCK ASSEMBLY (DOOR AJAR SWITCH) BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CARGO ROOM LAMP COMPUTER DATA LINES SYSTEM DOOR DR DOOR SW FRONT ROOM/MAP LAMP ASSEMBLY FUSE 11 FUSE 13 FUSE 9 FUSE BLOCK (J/B) GRN WIRE GROUND 1 GRY WIRE HOT AT ALL TIMES INTERIOR ROOM LAMP LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LEFT VANITY MIRROR LAMP LIN 2 TRUNK LUGGAGE LAMP LOCK LT BLU WIRE LT GRN WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH MAP LAMP LH MAP LAMP RH OFF OFF OFF ON DOOR OFF ON PNK WIRE PPL PWM ROOMLAMP 1 PWR DOOR LOCK PWR ECU PWR ROOM LAMP RED WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH RIGHT VANITY MIRROR LAMP RL DOOR SW ROOM LAMP ROOM LAMP BATT SAVER RR DOOR SW TAN WIRE TGATE STAT UNLOCK WHT WIRE YEL WIRE
