Nissan Kicks I (2016-2020) warning system switch Wiring diagrams
This page contains all the electrical diagrams for the component. warning system switch, in which he is found in the car Nissan Kicks I (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
warning system switch wiring diagram (1 of 3)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ADAS CONTROL UNIT (RIGHT END OF DASH)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BUZZER
BUZZER OUTPUT
CAN L
CAN-H
CAN-H PNK CAN-L WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONFIG
FEB SW
FEB SW IND
FUSE 29
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
ILL
ITS CAN-H
ITS CAN-L
LEFT BLIND SPOT WARNING INDICATOR
LEFT DOOR MIRROR
LEFT SIDE RADAR
LT BLU WIRE
PNK CAN-L WIRE
PNK WIRE
PPL ILL
RED WIRE
RIGHT BLIND SPOT WARNING INDICATOR
RIGHT DOOR MIRROR
RIGHT SIDE RADAR
SOW LAMP
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WARNING SYSTEM BUZZER (LEFT END OF DASH)
WARNING SYSTEM SWITCH
WHT WIRE
YEL WIRE
Go to component -> Blind spot monitoring circuit -> WARNING SYSTEM SWITCH
warning system switch wiring diagram (2 of 3)
ADAS CONTROL UNIT (RIGHT END OF DASH)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLS SW
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
BS SW
BUZZER
BUZZER OUT
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FEB SW
FEB SW IND
FUSE 18
FUSE 29
FUSE 3
FUSE 9
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
ILL
ITS CAN-H
ITS CAN-L
LT BLU WIRE
LT GRN WIRE
OUT SPEED SENS
OUTPUT SPEED SENSOR
PNK WIRE
POWER SUPPLY
PPL
PRI SPEED SENS
PRIMARY SPEED SENSOR
PWR ECU
RED WIRE
SEC SPEED SENS
SECONDARY SPEED SENSOR
SHIFT INTERLOCK SYSTEM
STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
WARNING BUZZER (LEFT END OF DASH)
WARNING SYSTEM SWITCH
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 2) -> WARNING SYSTEM SWITCH
warning system switch wiring diagram (3 of 3)
BASE
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR
DOOR MIRROR REMOTE CONTROL SWITCH
EARLY PRODUCTION
FRONT AUXILIARY INPUT JACKS
FRONT CONSOLE POWER SOCKET
FUSE 19
FUSE 31
FUSE BLOCK (J/B)
GND 2
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
INTELLIGENT KEY UNIT
LATE PRODUCTION
LT BLU WIRE
METER CONTROL SWITCH
METER ILLUMINATION
PNK WIRE
PPL
PUSH BUTTON IGNITION SWITCH
PWR
RED WIRE
RIGHT END OF DASH)
START BACKLIGHT
STEERING SWITCHES
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
VDC OFF SWITCH
W/ DRIVER ASSISTANCE SYSTEM
WARNING SYSTEM SWITCH
Go to component -> Instrument illumination circuit (2 of 2) -> WARNING SYSTEM SWITCH
