Nissan Kicks I (2016-2020) sensor incar temp Wiring diagram
This page shows the only wiring diagram for the component.sensor incar temp, which is found in the car Nissan Kicks I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sensor incar temp (1 of 1)
A/C AUTO AMPLIFIER (BOTTOM OF HVAC UNIT)
A/C SWITCH ASSEMBLY
ANALOG INPUT 6 (SOLAR LEVEL SENSOR)
AUTO ACC
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FRONT LEFT SEAT HEATER HIGH
FRONT LEFT SEAT HEATER LOW
FRONT RIGHT SEAT HEATER HIGH
FRONT RIGHT SEAT HEATER LOW
FUSE 4
FUSE 55
FUSE 58
FUSE 61
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK J
FUSIBLE LINK S
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
IN-VEHICLE SENSOR
LIN VEH 2
LT BLU WIRE
PNK WIRE
PPL
RED WIRE
SEATS SYSTEM
SENSOR INCAR TEMP
SHIELD
SUNLOAD SENSOR
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 4) -> SENSOR INCAR TEMP
