Nissan Kicks I (2016-2020) bpp sw Wiring diagrams

ABS IND. AV CONTROL UNIT BCM (BODY CONTROL MODULE) BLK WIRE BLS SW BLU WIRE BPP SW BRAKE FLUID LEVEL SWITCH BRAKE IND BRAKE OIL SW BRAKE PEDAL POSITION SWITCH BRAKE SW BRN WIRE BS SW CAN L CAN-H CHASSIS CONTROL MODULE (W/ BUILT IN STEERING ANGLE SENSOR) COMBINATION METER COMPUTER DATA COMPUTER DATA LINES SYSTEM ECM (UNDER REAR OF BATTERY) FLUID RESERVOIR) FUSE 18 FUSE 25 FUSE 3 FUSE 31 FUSE 32 FUSE BLOCK (J/B) GND 2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY-1 ENERGIZED HOT W/ IGNITION RELAY-2 ENERGIZED IC CAN H IC CAN L IGN LINES SYSTEM LT BLU WIRE LT GRN WIRE OP SIG PARKING BRAKE SWITCH PKB SIG PKB SW PNK WIRE PPL RED WIRE SHIFT INTERLOCK SYSTEM SLIP IND SOURCE STEERING ANGLE SENSOR STOP LAMP SWITCH TAN WIRE UNIFIED METER CONTROL UNIT VACUUM SENSOR (LEFT SIDE OF ENGINE COMPT) VDC OFF IND W/ INTELLIGENT AROUND VIEW MONITOR SYSTEM W/O INTELLIGENT AROUND VIEW MONITOR SYSTEM WHT WIRE YEL WIRE

ACCELERATOR PEDAL POSITION SENSOR ASCD STEERING SWITCH ASCD STR SW ASCD STR SW GND BATTERY BLK WIRE BLU WIRE BPP SW BRAKE SW BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISTANCE SENSOR EARLY PRODUCTION ECM GND ELECTRIC THROTTLE CONTROL ACTUATOR FUSE 42 FUSE 49 FUSE 53 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ECM RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED IC CAN H IC CAN L IGN IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LATE PRODUCTION LT GRN WIRE MAIN MTR (CLOSE) MTR OPEN PNK WIRE PPL RED WIRE RES+ SENS GND SENS PWR SPLY SENSOR 1 SENSOR 2 SET- TAN WIRE THROTTLE CONTROL MOTOR THROTTLE CONTROL MOTOR RELAY THROTTLE POSITION SENSOR WHT WIRE YEL WIRE
