Nissan Juke I facelift (2014-2019) manual mode shift down sig non-manual mode sig Wiring diagram
This page shows the only wiring diagram for the component.manual mode shift down sig non-manual mode sig, which is found in the car Nissan Juke I facelift (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram manual mode shift down sig non-manual mode sig (1 of 1)
AUTO
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CAN L
CAN-H
CAN-H PNK CAN-L PNK WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR (BASE OF SHIFT LEVER ASSEMBLY)
DETENTION SWITCH
DOOR LOCKS, ANTI-THEFT SYSTEMS
DOWN
GRN WIRE
GRY WIRE
ILL
INPUT SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
LT BLU WIRE
LT GRN WIRE
MANUAL
MANUAL MODE SHIFT DOWN SIG NON-MANUAL MODE SIG
MANUAL MODE SHIFT UP SIG
MANUAL MODE SIG
MODE SELECT SWITCH
ORG/ WIRE
OUTPUT SPEED SENSOR (RIGHT SIDE OF TRANSMISSION)
PADDLE SHIFTER (SHIFT-DOWN)
PADDLE SHIFTER (SHIFT-UP)
PADDLE SHIFTER UP SW SIG
PARK POSITION SWITCH
PNK WIRE
POSITION SELECT SWITCH
PPL
PPL PADDLE SHIFTER DOWN SW SIG
PRIMARY SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
RED WIRE
RIGHT END OF DASH)
SHIFT INTERLOCK SYSTEM
SHIFT LOCK SOLENOID
STARTING/ CHARGING SYSTEM
TAN WIRE
TRANSMISSION RANGE SWITCH
WHT WIRE
YEL WIRE
Go to component -> A/t circuit, except nismo (2 of 2) -> MANUAL MODE SHIFT DOWN SIG NON-MANUAL MODE SIG
