Nissan Juke I facelift (2014-2019) awd mode switch Wiring diagrams
This page contains all the electrical diagrams for the component. awd mode switch, in which he is found in the car Nissan Juke I facelift (2014-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram awd mode switch (1 of 2)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
AWD CONTROL MODULE
AWD IND, AWD-V IND
AWD MODE SWITCH
AWD SOL L+ PPL AWD SOL L-
AWD SOL R-
AWD SW
AWD-V SW
BLK WIRE
BLU WIRE
CAN L
CAN-H
CAN-H PNK CAN-L WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
EXCEPT NISMO
FUSE 12
FUSE 23
FUSE 3
FUSE 33
FUSE BLOCK (J/B)
FUSE HOLDER
FUSE, FUSIBLE LINK BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN SW
LEFT ELECTRIC CONTROLLED COUPLING
LT GRN WIRE
NCA WIRE
NISMO
PNK WIRE
PPL
RED WIRE
RIGHT ELECTRIC CONTROLLED COUPLING
SOL BAT
STEERING ANGLE SENSOR
TCM (TRANSMISSION CONTROL MODULE)
WHT WIRE
YEL WIRE
Go to component -> Awd circuit -> AWD MODE SWITCH
Wiring diagram awd mode switch (2 of 2)
A/C CONTROL
AUDIO UNIT
AUTOMATIC A/C
AWD MODE SWITCH
BLK WIRE
COMBINATION SWITCH (SPIRAL CABLE)
CVT SHIFT SELECTOR
DOOR MIRROR REMOTE CONTROL SWITCH
GLOVE BOX LAMP)
GRN WIRE
GRY WIRE
HAZARD SWITCH
LEFT HEATED SEAT SWITCH
MANUAL A/C
MULTI DISPLAY UNIT
NAVI CONTROL UNIT
PNK WIRE
PPL
RIGHT END OF DASH)
RIGHT HEATED SEAT SWITCH
STEERING SWITCH
VDC OFF SWITCH
W/O NAVIGATION W/ NAVIGATION
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> AWD MODE SWITCH
