Car Wiring Diagrams for Horn circuit for Nissan Juke I (2010-2014)

BLK/RED WIRE BLU WIRE BRN WIRE COMBINATION SWITCH (SPIRAL CABLE) COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN) FUSE 35 FUSE, FUSIBLE LINK, RELAY BOX FUSE, FUSIBLE LINK, RELAY BOX (ON BATTERY (+) POST) GRN WIRE HORN (HIGH) HORN (HIGH) (FRONT OF ENGINE COMPT) HORN (LOW) HORN (LOW) (FRONT OF ENGINE COMPT) HORN RELAY HORN RELAY (IN IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)) HORN SWITCH HOT AT ALL TIMES IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT GRN WIRE
