Nissan Juke I (2010-2014) request opener switch switch back door opener switch Wiring diagram
This page shows the only wiring diagram for the component.request opener switch switch back door opener switch, which is found in the car Nissan Juke I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram request opener switch switch back door opener switch (1 of 1)
40 39 30 PNK CAN-L CAN-H DOOR OPEN SW WIRE
51 43 53 BACK DOOR REQ SW BACK DOOR SW DOOR OPENER OUT PNK WIRE
70 57 67 BAT (F/L) BAT (FUSE) GND
BACK DOOR SWITCH
BCM (BODY CONTROL MODULE) (LEFT KICK PANEL)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 9 (J/B) (LEFT END OF DASH)
FUSE BLOCK
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK G
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
OPENER ACTUATOR BACK DOOR LOCK ASSEMBLY
PNK WIRE
REQUEST OPENER SWITCH SWITCH BACK DOOR OPENER SWITCH
YEL WIRE
Go to component -> Back door opener circuit, with intelligent key unit -> REQUEST OPENER SWITCH SWITCH BACK DOOR OPENER SWITCH
