Nissan Juke I (2010-2014) ipod connection recognition pnk accessory detect Wiring diagram

ACC DETECT ACC IDENTIFY ACCESSORY IDENTIFY AM-FM MAIN ANT AMP ON SIG ANTENNA AMP ANTENNA BASE AUDIO UNIT AV COMM (H) SHIELD SHIELD AV COMM (L) BATTERY BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMM COMPUTER DATA LINES SYSTEM CONN RECOG GRN WIRE GRY WIRE IPOD ADAPTER IPOD CONNECTION RECOGNITION PNK ACCESSORY DETECT WIRE IPOD CONNECTOR IPOD SIG LH (-) IPOD SIG RH (+) IPOD SOUND SIG GND IPOD SOUND SIG LH (+) IPOD SOUND SIG RH (+) IPOD SOUND SIG RH (-) SHIELD SHIELD LT BLU WIRE LT GRN WIRE MICRO GND MICRO SIG + MICRO VCC MICROPHONE NCA WIRE PNK WIRE PPL PPL COMM RED WIRE ROD ANTENNA SATELLITE ANTENNA SEEK DOWN SEEK UP SHEILD SHIELD SHIELD SHIELD SIG LH (+) SIG RH (+) SOUND SIG GND SOURCE STEERING SWITCH TELE- PHONE TELE- PHONE END USB D+ SIG VOLUME DOWN UP VOLUME- W/O INTELLIGENT KEY W/ INTELLIGENT KEY WHT WIRE YEL WIRE
