Nissan Juke I (2010-2014) clutch interlock Wiring diagram
This page shows the only wiring diagram for the component.clutch interlock, which is found in the car Nissan Juke I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram clutch interlock (1 of 1)
ACC/ON
BATTERY
BATTERY TERMINAL W/ FUSIBLE LINK
BCM (BODY CONTROL MODULE) (LEFT KICK PANEL)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CAN-H
CHARGING CIRCUIT
CLUTCH INTERLOCK
CLUTCH INTERLOCK SW (W/ M/T)
COMPUTER DATA LINES SYSTEM
FUSE 7
FUSE BLOCK (J/B) (LEFT END OF DASH)
FUSE, FUSIBLE LINK, RELAY BOX (ON BATTERY (+) POST)
FUSIBLE LINK A
FUSIBLE LINK H
GRN WIRE
HOT AT ALL TIMES
IGNITION RELAY
ILLUMINATION
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PASS DOOR REQ SW
PNK CAN-L WIRE
PNK WIRE
PPL
PPL ACC/ON IND
PUSH BUTTON IGNITION SWITCH
PUSH SW
PUSS-BTN IGN SW ILL GND
PUSS-BTN IGN SW ILL PWR
RED WIRE
STARTER CONTROL RELAY
STARTER MOTOR
STARTER RELAY
STARTER RELAY CONT
SWITCH (ON CLUTCH PEDAL BRACKET)
WHT WIRE
YEL WIRE
Go to component -> Starting circuit, m/t with intelligent key -> CLUTCH INTERLOCK
