Nissan GT-R I facelift 3 (2016-2020) Automatic a/c circuit

A/C AUTO AMP A/C AUTO AMP CONN REC SIGNAL AMBIENT SENSOR SIGNAL PNK WIRE A/C AUTO AMPLIFIER (LOWER CENTER OF DASH) A/C CONTROL A/C LAN SIGNAL ACC PWR SPLY AMBIENT SENSOR AMBIENT SENSOR GROUND AMBIENT SENSOR SIGNAL AMP AV CONTROL UNIT BATTERY PWR SPLY BCM (BODY CONTROL MODULE) (LOWER RIGHT END OF DASH) BLK WIRE BLOWER MOTOR BLOWER RELAY BLU WIRE BLWR FAN MTR RLY CTRL BLWR MTR CTRL SIGNAL CAN L CAN-H CAN-H PNK CAN-L WIRE COMBINATION METER COMM (AMP-CONT) PNK COMM (CONT-AMP) WIRE COMPRESSOR) COMPUTER DATA LINES SYSTEM CONN REC SIGNAL DEFOGGER SYSTEM EACH DR MTR PWR SPLY ECV (+) ECV SIGNAL FUSE 19 FUSE 21 FUSE 22 FUSE 3 FUSE 6 FUSE BLOCK (J/B) FUSIBLE LINK E FUSIBLE LINK HOLDER GRN WIRE GROUND HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY ENERGIZED IGNITION PWR SPLY IN-VEHICLE SENSOR IN-VEHICLE SENSOR SIGNAL INTAKE SENSOR INTAKE SENSOR SIGNAL LT BLU WIRE LT GRN WIRE MAGNET CLUTCH PNK WIRE PPL PPL IGN RED WIRE RR WINDOW DEF F/B RR WINDOW DEF SW RX PNK TX WIRE SENSOR GROUND SUNLOAD SENSOR SUNLOAD SENSOR SIGNAL TAN WIRE WHT WIRE YEL WIRE

A/C RELAY AMP BLK WIRE BLK/WHT WIRE BLU WIRE CAN COMM LINE COMPUTER DATA LINES SYSTEM COOLING FAN CONTROL MODULE 1 COOLING FAN CONTROL MODULE 2 COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 COOLING FAN RELAY 1 COOLING FAN RELAY 2 ECM (RIGHT END OF DASH) ECT SENSOR ENGINE COOLANT TEMPERATURE SENSOR FUSE 49 FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK C FUSIBLE LINK F FUSIBLE LINK HOLDER FUSIBLE LINK M GRN WIRE HOT AT ALL TIMES IGNITION RELAY INTAKE DOOR MOTOR IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LEFT AIR MIX DOOR MOTOR MODE DOOR MOTOR PNK WIRE PPL RED WIRE REFR PRESS SENS REFRIGERANT PRESSURE SENSOR RIGHT AIR MIX DOOR MOTOR RIGHT END OF DASH) SENS GND SENS PWR SPLY TAN WIRE WHT WIRE YEL WIRE
