Nissan GT-R I facelift 3 (2016-2020) spd out sig wiring diagram
This page shows the only wiring diagram for the component.spd out sig, which is found in the car Nissan GT-R I facelift 3 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
spd out sig wiring diagram (1 of 1)
AXIS A VALVE (+)
AXIS B VALVE (+)
BACKUP LAMP RELAY
BLK WIRE
BLU WIRE
BRN WIRE
CAN COMM LINE
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
FUSE 4
FUSE 7
FUSE 9
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PADDLE SHIFTER (SHIFT-DOWN SWITCH)
PADDLE SHIFTER (SHIFT-UP SWITCH)
PARK POSITION SWITCH
PNK WIRE
PPL
R MODE LAMP
R MODE SWITCH
RED WIRE
RIGHT END OF DASH)
SAVE MODE LAMP
SAVE MODE SWITCH
SEQUENCE VALVE (+)
SET-UP SWITCH
SHIFT VALVE 1
SHIFT VALVE 2 +
SHIFT VALVE 3(+)
SHIFT VALVE 4 (+)
SPD OUT SIG
STEERING SWITCH
STOP LAMP SWITCH
TAN WIRE
TCM
WHT WIRE
Go to component -> A/t circuit (2 of 3) -> SPD OUT SIG
