Nissan GT-R I facelift 3 (2016-2020) s/l unit comm Wiring diagrams

This page contains all the electrical diagrams for the component. s/l unit comm, in which he is found in the car Nissan GT-R I facelift 3 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram s/l unit comm (1 of 3)

Wiring diagram s/l unit comm for Nissan GT-R I facelift 3 (2016-2020) (1 of 3)

Get access

A/T SHIFT SELECTOR A/T SHIFT SELECTOR PWR SPLY ALL DR, FUEL LID LK O/P BAT (F/L) BAT FUSE BCM (BODY CONTROL MODULE) (LOWER RIGHT END OF DASH) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM DETENTION SWITCH DR LK/UNLK SW LK DR LK/UNLK SW UNLK DRV DR ANT+ DRV DR REQUEST SW DRV DR SW DRV DR UNLK SENS DRV DR, FUEL LID UNLK O/P FUSE 10 FUSE 11 FUSE 31 FUSE 4 FUSE 6 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK I GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IMMO ANT CTRL IMMO ANT SIG [+] INSIDE KEY ANTENNA (CONSOLE) INSIDE KEY ANTENNA (INSTRUMENT CENTER) INTELLIGENT KEY WARNING BUZZER (ENGINE ROOM) INTERIOR ROOM LP PWR SPLY KEY SLOT ILL O/P KEY SLOT SW KEY WARN BUZZER (ENG ROOM) KEYLESS ENTRY RECEIVER COMM KEYLESS ENTRY RECEIVER PWR SPLY LEFT FRONT TURN SIG LEFT OUTSIDE HANDLE (REQUEST SWITCH) LEFT REAR TURN SIG LT BLU WIRE LT GRN WIRE OUTSIDE KEY ANTENNA (DRIVER SIDE) OUTSIDE KEY ANTENNA (PASSENGER SIDE) PASS DR ANT+ PASS DR REQUEST SW PASS DR SW PASS DR UNLK O/P PNK WIRE PPL PUSH SW REAR BUMPER ANT+ RECEIVER GND RED WIRE REMOTE KEYLESS ENTRY RECEIVER RIGHT FRONT TURN SIG RIGHT OUTSIDE HANDLE (REQUEST SWITCH) RIGHT REAR TURN SIG ROOM LP TIMER CTRL S/L CONDITION 1 S/L CONDITION 2 S/L UNIT COMM S/L UNIT PWR SPLY SECURITY IND SECURITY INDICATOR LAMP SHIFT P SIG OUT TAN WIRE TRUNK CANCEL SW TRUNK LID REQUEST SW TRUNK ROOM ANT+ TRUNK ROOM LAMP SW TRUNK, TAILGATE, FUEL DOORS SYSTEM WHT WIRE YEL WIRE

Go to component -> Anti-theft circuit (1 of 3) -> S/L UNIT COMM

Wiring diagram s/l unit comm (2 of 3)

Wiring diagram s/l unit comm for Nissan GT-R I facelift 3 (2016-2020) (2 of 3)

Get access

A/T SHIFT SELE- CTOR PWR SPLY S/L CONDITION 1 ACC IND ACC RLY CONT AIR CONDITIONING SYSTEM BATT (F/L) BATT FUSE BCM (BODY CONTROL MODULE) (LOWER RIGHT END OF DASH) BLK WIRE BLU WIRE BRN WIRE BUZZER CAN L CAN-H COMBI IN 1 COMBI IN 2 COMBI IN 3 COMBI IN 4 COMBI IN 5 COMBI OUT 1 COMBI OUT 2 COMBI OUT 3 COMBI OUT 4 COMBI OUT 5 COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DIMMER SIG DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, HEADLIGHTS, ANTI-THEFT SYSTEMS DR DOOR ANT+ DR LOCK OUT (ALL) DR REQ SW DR UNLOCK OUT (DRV) DR UNLOCK OUT (PASS) DR UNLOCK SENS DRV DR SW FUSE 10 FUSE 3 FUSE 7 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK I GRN WIRE GRY WIRE HAZARD SW HEADLIGHT SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS, INTERIOR LIGHTS, EXTERIOR LIGHTS SYSTEMS HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED IGN F/B IGN RELAY IGN RLY CONT IGN SW ILL PWR IMMO ANT CTRL IMMO ANT SIG [+] KEY SLOT ILL KEY SLOT SW LF TURN SIG LOCK IND LOCK/UNLOCK SW LR TURN SIG LT BLU WIRE LT GRN WIRE MOTOR RLY CONT NAVIGATION, SOUND SYSTEMS ON IND. OPTICAL SENS PASS DOOR ANT+ PASS DR SW PASS REQ SW PNK WIRE POWER DISTRIBUTION SYSTEM POWER WINDOWS SYSTEM PPL PUSH BUTTON IGNITION SWITCH PUSH IGN SW ILL GND PUSH SW PUSH SWITCH PWR WINDOW SPLY (BATT) PWR WINDOW SPLY (RAP) REAR BUMPER ANT+ REAR DEF RLY RECEIVER COMM RECEIVER GND RECEIVER PWR RECEIVER/SENS RED WIRE RF TURN SIG ROOM LAMP PWR SPLY ROOM LAMP TIMER CTRL RR DEF SW RR TURN SIG S/L CONDITION 2 S/L UNIT COMM S/L UNIT PWR SECURITY IND SHIFT N/P SHIFT P STARTER RLY CONT STARTING/CHARGING SYSTEM STEP LAMP STOP LAMP SW 1 STOP LAMP SW 2 TAN WIRE TRUNK ANT+ TRUNK CANCEL TRUNK LAMP OUT TRUNK LID REQ SW TRUNK LID SW TRUNK OPENER OUT TRUNK SW TRUNK, TAILGATE, FUEL DOORS SYSTEM UNLOCK SW WHT WIRE YEL WIRE

Go to component -> Body control modules circuit -> S/L UNIT COMM
