Nissan GT-R I facelift 3 (2016-2020) prk position sw sig Wiring diagram
This page shows the only wiring diagram for the component.prk position sw sig, which is found in the car Nissan GT-R I facelift 3 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram prk position sw sig (1 of 1)
A/T SHIFT SELECTOR
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 4
FUSE 7
FUSE 9
FUSE BLOCK (J/B)
HOT AT ALL TIMES
HOT IN ON OR START
PARK POSITION SWITCH
PNK WIRE
PPL
PRK POSITION SW SIG
PWR SPLY
SHIFT LK SOL CTRL SIG
SHIFT LOCK SOLENOID
STOP LAMP SWITCH
STP LP SW SIG
TAN WIRE
TCM
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> PRK POSITION SW SIG
