Nissan GT-R I facelift 3 (2016-2020) ign sig 3 Wiring diagram

A/F SENS 1 HTR (BANK 1) A/F SENS 1 HTR (BANK 2) AVCC BATT CURRENT SENS BATTERY CURRENT SENSOR BLK WIRE BLU WIRE BRN WIRE CAMSHAFT PHASE BANK 1 CAMSHAFT POSITION SENSOR (PHASE) (BANK 1) ECM GND ELECTRIC CTRL MUFFLER ENG COOLANT TEMP SENS ENG OIL TEMP SENS EVAP CANISTER VENT CTRL VLV EVAP CANISTER PURGE VOLUME CTRL SOL VLV IGN SIG 2 FPCM CHECK FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL INJECTOR 5 FUEL INJECTOR 6 FUEL PUMP CTRL FUEL TANK TEMP SENS GRN WIRE GRY WIRE IGN SIG 1 IGN SIG 3 IGN SIG 4 IGN SIG 5 IGN SIG 6 IGNITION COIL 1 (W/ POWER TRANSISTOR) IGNITION COIL 2 (W/ POWER TRANSISTOR) IGNITION COIL 3 (W/ POWER TRANSISTOR) IGNITION COIL 4 (W/ POWER TRANSISTOR) IGNITION COIL 5 (W/ POWER TRANSISTOR) IGNITION COIL 6 (W/ POWER TRANSISTOR) INTAKE AIR TEMP SENS INTAKE AIR TEMPERATURE SENSOR LT BLU WIRE LT GRN WIRE MASS AIR FLOW SENS MASS AIR FLOW SENS MANIFOLD ABSOLUTE PRESS SENS MASS AIR FLOW SENSOR (BANK 1) MASS AIR FLOW SENSOR (BANK 2) NCA WIRE OUT PUT PNK WIRE PPL RED WIRE RIGHT END OF DASH) SENS GND SENS GND SECONDARY AIR INJ SYS MASS AIR FLOW SENS SLD VLV BANK 1 SLD VLV BANK 2 SPARK PLUG T P SENS 1 (BANK 1) T P SENS 1 (BANK 2) T P SENS 2 (BANK 1) T P SENS 2 (BANK 2) TAN WIRE THR MTR (CLS) THR MTR (OPEN) (BANK 1) THR MTR (OPEN) (BANK 2) THR MTR PWR SPLY (BANK 1) THR MTR PWR SPLY (BANK 2) TURBOCHARGER BOOST CTRL SOL VAV SENS GND WHT WIRE YEL WIRE
