Nissan GT-R I facelift 3 (2016-2020) headlamp high Wiring diagram
This page shows the only wiring diagram for the component.headlamp high, which is found in the car Nissan GT-R I facelift 3 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlamp high (1 of 1)
AV CONTROL UNIT
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FRONT FOG LAMP RELAY
FUSE 50
FUSE 51
FUSE 54
FUSE 55
FUSE 56
FUSE 57
FUSE 58
FUSIBLE LINK D
FUSIBLE LINK HOLDER
GRN WIRE
GROUND
HEADLAMP HIGH
HEADLAMP HIGH RELAY
HEADLAMP LOW
HEADLAMP LOW RELAY
HEADLAMP WARNING IND
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION PWR SPLY
ILL (+) GROUND
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LED HEADLAMP CONTROL MODULE
LEFT DAYTIME RUNNING LIGHT
LEFT FRONT COMBINATION LAMP
LH HEADLAMP WARNING SIG
LT GRN WIRE
PARKING BRAKE
PARKING BRAKE SWITCH
PNK WIRE
POWER SUPPLY
PPL
RED WIRE
RH HEADLAMP WARNING SIG
RIGHT DAYTIME RUNNING LIGHT
RIGHT END OF DASH)
RIGHT FRONT COMBINATION LAMP
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit (2 of 2) -> HEADLAMP HIGH
