Nissan GT-R I facelift 3 (2016-2020) frt microphone sig Wiring diagrams

This page contains all the electrical diagrams for the component. frt microphone sig, in which he is found in the car Nissan GT-R I facelift 3 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram frt microphone sig (1 of 2)

Wiring diagram frt microphone sig for Nissan GT-R I facelift 3 (2016-2020) (1 of 2)

Get access

ACC PWR SPLY AV COMMUNICATION SIG (H) AV COMMUNICATION SIG (L) BACK BLK WIRE BLU WIRE BOSE AMPLIFIER (UNDER DRIVER'S SEAT) BRN WIRE CAN-H PNK CAN-L WIRE COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM ENGINE SPEED SIG ENTER FRONT MICROPHONE (ACTIVE NOISE CANCELLATION) FRT MICROPHONE SIG FRT MICROPHONE SIG GND GRN WIRE GRY WIRE ILLUM LH SOUND SIG (-) LT BLU WIRE LT GRN WIRE MENU DOWN MENU UP MRK NCA WIRE PNK WIRE PPL REAR MICROPHONE (ACTIVE NOISE CANCELLATION) RED WIRE RH SOUND SIG (+) RR MICROPHONE SIG RR MICROPHONE SIG GND SHIELD SOURCE START STOP STEERING SWITCH TCM TEL VOICE GUIDANCE SIG (-) VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Navigation circuit, w/ bose (2 of 4) -> FRT MICROPHONE SIG

Wiring diagram frt microphone sig (2 of 2)

Wiring diagram frt microphone sig for Nissan GT-R I facelift 3 (2016-2020) (2 of 2)

Get access

Go to component -> Radio circuit, w/ bose (2 of 4) -> FRT MICROPHONE SIG

Nissan GT-R I facelift 3 (2016-2020) frt microphone sig Wiring diagrams

Wiring diagram frt microphone sig (1 of 2)

List of components:

Wiring diagram frt microphone sig (2 of 2)

List of components:
