Nissan GT-R I facelift 3 (2016-2020) front control module Wiring diagram

ACTUATOR CONTROL MODULE AXIS A FEED PRESSURE SOLENOID VALVE AXIS B FEED PRESSURE SOLENOID VALVE BLK WIRE BLU WIRE BRN WIRE CLUTCH A PRESSURE SENSOR CLUTCH A SENS (-) CLUTCH A SENS SIG CLUTCH A SOLENOID VALVE CLUTCH A SPD SENS (-) CLUTCH A SPEED SENSOR CLUTCH A VALVE (-) CLUTCH B PRESSURE SENSOR CLUTCH B SENS (-) CLUTCH B SENS SIG CLUTCH B SOLENOID VALVE CLUTCH B SPEED SENSOR CLUTCH B VALVE (-) FLOW VALVE (+) FLUID TEMPERATURE SENSOR FRONT CONTROL MODULE GRN WIRE GRY WIRE LINE PRESS SENS LINE PRESS SENS SIG LINE PRESS VALVE (-) LINE PRESSURE SENSOR LINE PRESSURE SOLENOID VALVE LT BLU WIRE LT GRN WIRE LUBRICATING FLOW SOLENOID VALVE OUT SPD SENS OUT SPD SENS (-) (PINS: 108 TO 112 NOT USED) OUT SPD SENS SIG OUTPUT SHAFT SPEED SENSOR PARK POS SW SIG PNK WIRE POSITION SENSOR POSITION SENSOR 1 POSITION SENSOR 2 PPL PPL LINE PRESS VALVE (+) RED WIRE SEQUENCE SOLENOID VALVE SHIELD SHIFT SOLENOID VALVE 1 SHIFT SOLENOID VALVE 2 SHIFT SOLENOID VALVE 3 SHIFT SOLENOID VALVE 4 TAN WIRE TCM TEMP SENS TRANSMISSION UNIT TRANSMISSION UNIT (ON TRANSMISSION) WHT WIRE YEL WIRE
