Nissan GT-R I facelift 3 (2016-2020) driver side power window motor Wiring diagram
This page shows the only wiring diagram for the component.driver side power window motor, which is found in the car Nissan GT-R I facelift 3 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side power window motor (1 of 1)
AU AD
BAT (F/L)
BAT (FUSE) GND
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
DRIVER SIDE
DRIVER SIDE DOOR SWITCH
DRIVER SIDE POWER WINDOW MOTOR
DRV DR SW
FUSE 10
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK I
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILLUM
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
MODULE
ORG/ WIRE
PASS DR SW
PASSENGER SIDE
PASSENGER SIDE DOOR SWITCH
PASSENGER SIDE POWER WINDOW MOTOR
POWER WINDOW MAIN SWITCH
POWER WINDOW SUB-SWITCH
PPL
PWR SPLY (BAT)
PWR SPLY (RAP)
RED WIRE
WHT WIRE
Go to component -> Power windows circuit -> DRIVER SIDE POWER WINDOW MOTOR
