Nissan GT-R I facelift 2 (2014-2016) source sw Wiring diagrams

This page contains all the electrical diagrams for the component. source sw, in which he is found in the car Nissan GT-R I facelift 2 (2014-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram source sw (1 of 6)

Wiring diagram source sw for Nissan GT-R I facelift 2 (2014-2016) (1 of 6)
Get lifetime access to Nissan GT-R I facelift 2 (2014-2016)

BLU WIRE COMBINATION SWITCH (SPIRAL CABLE) FUSE 4 FUSE 8 FUSE BLOCK (J/B) GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN WIRE MICROPHONE (IN OVERHEAD CONSOLE) MICROPHONE GND MICROPHONE SIG MICROPHONE VCC NCA WIRE ORG/ WIRE PNK WIRE PPL REAR SPEAKER (-) SEEK DOWN SEEK UP SHIELD SOURCE SW START/ VR STOP SW STEERING SWITCH TEL VOLUME MRK SW UP VOLUME DOWN WHT WIRE YEL WIRE

Go to component -> Navigation circuit, base (2 of 3) -> SOURCE SW

Wiring diagram source sw (2 of 6)

Wiring diagram source sw for Nissan GT-R I facelift 2 (2014-2016) (2 of 6)
Get lifetime access to Nissan GT-R I facelift 2 (2014-2016)

BATTERY BLK WIRE BLU WIRE BOSE AMP ON SIG BOSE AMPLIFIER (UNDER DRIVER'S SEAT) BRN WIRE CENTER SPEAKER CNTR SPEAKER(+) COMBINATION SWITCH (SPIRAL CABLE) GRN WIRE GRY WIRE ILLUM LEFT FRONT DOOR SPEAKER LEFT FRONT DOOR SQUAWKER LEFT REAR SPEAKER LEFT TWEETER LF DR (+) LF DR SQU (-) LF+ LR (-) LT BLU WIRE LT GRN WIRE MRK NCA WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RF DR RF DR SQU (+) RF+ RIGHT FRONT DOOR SPEAKER RIGHT FRONT DOOR SQUAWKER RIGHT REAR SPEAKER RIGHT TWEETER RR (-) SEEK DOWN SEEK UP SHIELD SND SIG WFR (+) SOURCE SW START STOP STEERING SWITCH TEL VOLUME SW UP VOLUME DOWN VR SW WFR AMP ON SIG WHT WIRE YEL WIRE

Go to component -> Navigation circuit, bose w/ nismo (2 of 3) -> SOURCE SW

Wiring diagram source sw (3 of 6)

Wiring diagram source sw for Nissan GT-R I facelift 2 (2014-2016) (3 of 6)
Get lifetime access to Nissan GT-R I facelift 2 (2014-2016)

AUDIO SIG + AUDIO SIG WOOFER BATTERY PWR SPLY BLK WIRE BLU WIRE BOSE AMPLIFIER BRN WIRE CENTER SPEAKER COMBINATION SWITCH (SPIRAL CABLE) DR SPEAKER DR SQUAWKER GRN WIRE GRY WIRE ILLUM LEFT FRONT DOOR SPEAKER LEFT FRONT DOOR SQUAWKER LEFT REAR SPEAKER LEFT TWEETER LH AUDIO SIG LH AUDIO SIG FR LT BLU WIRE LT GRN WIRE MRK NCA WIRE PNK WIRE PPL RED WIRE RH AUDIO SIG RH AUDIO SIG FR RIGHT FRONT DOOR SPEAKER RIGHT FRONT DOOR SQUAWKER RIGHT REAR SPEAKER RIGHT TWEETER RR SPEAKER (+) SEEK DOWN SEEK UP SHIELD SOURCE SW START STOP STEERING SWITCH TAN WIRE TEL SW VOL DOWN VOL UP VR SW WHT WIRE WOOFER WOOFER AMP ON SIG YEL WIRE

Go to component -> Navigation circuit, bose w/o nismo (2 of 4) -> SOURCE SW

Wiring diagram source sw (4 of 6)

Wiring diagram source sw for Nissan GT-R I facelift 2 (2014-2016) (4 of 6)
Get lifetime access to Nissan GT-R I facelift 2 (2014-2016)

BLU WIRE COMBINATION SWITCH (SPIRAL CABLE) FUSE 4 FUSE 8 FUSE BLOCK (J/B) GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN WIRE MICROPHONE (IN OVERHEAD CONSOLE) MICROPHONE GND MICROPHONE SIG MICROPHONE VCC NCA WIRE ORG/ WIRE PNK WIRE PPL REAR SPEAKER (-) SEEK DOWN SEEK UP SHIELD SOURCE SW START/ VR STOP SW STEERING SWITCH TEL VOLUME MRK SW UP VOLUME DOWN WHT WIRE YEL WIRE

Go to component -> Radio circuit, base (2 of 3) -> SOURCE SW

Wiring diagram source sw (5 of 6)

Wiring diagram source sw for Nissan GT-R I facelift 2 (2014-2016) (5 of 6)
Get lifetime access to Nissan GT-R I facelift 2 (2014-2016)

BATTERY BLK WIRE BLU WIRE BOSE AMP ON SIG BOSE AMPLIFIER (UNDER DRIVER'S SEAT) BRN WIRE CENTER SPEAKER CNTR SPEAKER(+) COMBINATION SWITCH (SPIRAL CABLE) GRN WIRE GRY WIRE ILLUM LEFT FRONT DOOR SPEAKER LEFT FRONT DOOR SQUAWKER LEFT REAR SPEAKER LEFT TWEETER LF DR (+) LF DR SQU (-) LF+ LR (-) LT BLU WIRE LT GRN WIRE MRK NCA WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RF DR RF DR SQU (+) RF+ RIGHT FRONT DOOR SPEAKER RIGHT FRONT DOOR SQUAWKER RIGHT REAR SPEAKER RIGHT TWEETER RR (-) SEEK DOWN SEEK UP SHIELD SND SIG WFR (+) SOURCE SW START STOP STEERING SWITCH TEL VOLUME SW UP VOLUME DOWN VR SW WFR AMP ON SIG WHT WIRE YEL WIRE

Go to component -> Radio circuit, bose w/ nismo (2 of 3) -> SOURCE SW

Wiring diagram source sw (6 of 6)

Wiring diagram source sw for Nissan GT-R I facelift 2 (2014-2016) (6 of 6)
Get lifetime access to Nissan GT-R I facelift 2 (2014-2016)

AUDIO SIG + AUDIO SIG WOOFER BATTERY PWR SPLY BLK WIRE BLU WIRE BOSE AMPLIFIER BRN WIRE CENTER SPEAKER COMBINATION SWITCH (SPIRAL CABLE) DR SPEAKER DR SQUAWKER GRN WIRE GRY WIRE ILLUM LEFT FRONT DOOR SPEAKER LEFT FRONT DOOR SQUAWKER LEFT REAR SPEAKER LEFT TWEETER LH AUDIO SIG LH AUDIO SIG FR LT BLU WIRE LT GRN WIRE MRK NCA WIRE PNK WIRE PPL RED WIRE RH AUDIO SIG RH AUDIO SIG FR RIGHT FRONT DOOR SPEAKER RIGHT FRONT DOOR SQUAWKER RIGHT REAR SPEAKER RIGHT TWEETER RR SPEAKER (+) SEEK DOWN SEEK UP SHIELD SOURCE SW START STOP STEERING SWITCH TAN WIRE TEL SW VOL DOWN VOL UP VR SW WHT WIRE WOOFER WOOFER AMP ON SIG YEL WIRE

Go to component -> Radio circuit, bose w/o nismo (2 of 4) -> SOURCE SW
