Nissan GT-R I (2007-2011) accessory detect Wiring diagrams

This page contains all the electrical diagrams for the component. accessory detect, in which he is found in the car Nissan GT-R I (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram accessory detect (1 of 2)

Wiring diagram accessory detect for Nissan GT-R I (2007-2011) (1 of 2)

Get lifetime access to Nissan GT-R I (2007-2011)

ACCESSORY DETECT ACCESSORY IDENTIFY AV COMM (H) AV COMM (L) BATTERY BLK WIRE BLU WIRE BRN WIRE CHARGE POWER COMBINATION SWITCH COMM FUSE 8 FUSE BLOCK (J/B) (LEFT KICK PANEL) GRN WIRE GRY WIRE HOT AT ALL TIMES ILLUM IPOD ADAPTER (OPTION CONNECTOR) IPOD CONNECTION IPOD SIDE (OPTION CONNECTOR) IPOD SOUND SIG GND LH IPOD SOUND SIG (+) LT BLU WIRE NCA WIRE ORG/ WIRE PNK WIRE PPL PPL PNK WIRE RED WIRE RH IPOD SOUND SIG (+) SEEK SEEK UP DOWN SW SHIELD SOURCE SPIRAL CABLE (IN STEERING COLUMN) START/ VR STOP SW STEERING SWITCH TEL VOLUME MRK SW DOWN UP VOLUME- WHT WIRE YEL WIRE

Go to component -> Navigation circuit, base (2 of 3) -> ACCESSORY DETECT

Wiring diagram accessory detect (2 of 2)

Wiring diagram accessory detect for Nissan GT-R I (2007-2011) (2 of 2)

Get lifetime access to Nissan GT-R I (2007-2011)

Go to component -> Radio circuit, base (2 of 3) -> ACCESSORY DETECT
