Car Wiring Diagrams for Differential lock circuit for Nissan Frontier D41 (2021-2024)

BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM DIFF LOCK CU DIFF LOCK IND DIFF LOCK SW DIFF LOCK SW (OFF) V BATTERY DIFF LOCK SW (ON) DIFFERENTIAL LOCK CONTROL UNIT DIFFERENTIAL LOCK MODE SWITCH DIFFERENTIAL LOCK POSITION SWITCH DIFFERENTIAL LOCK SOLENOID FUSE 13 FUSE 30 FUSE 31 FUSE 6 FUSE 62 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX 1 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED IGN LT BLU WIRE LT GRN WIRE PNK WIRE PPL PPL/GRN WIRE PPL/RED WIRE PPL/TAN WIRE RED WIRE RIGHT END OF DASH) SOL BATT SOLENOID SSS UNIFIED METER CONTROL UNIT WHT WIRE YEL WIRE
