Nissan Frontier D41 (2021-2024) crash zone shield Wiring diagram
This page shows the only wiring diagram for the component.crash zone shield, which is found in the car Nissan Frontier D41 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crash zone shield (1 of 1)
A/C COMPRESSOR
AIR BAG DIAGNOSIS SENSOR UNIT
BLK WIRE
BRAKE FLUID LEVEL SWITCH
CONDENSER 1
CRASH ZONE SENSOR
CRASH ZONE SHIELD
FRONT WASHER MOTOR
FRONT WIPER MOTOR
GRN WIRE
GRY WIRE
HOOD SWITCH
HORN
IGNITION COIL 1 (W/ POWER TRANSISTOR)
IGNITION COIL 2 (W/ POWER TRANSISTOR)
IGNITION COIL 3 (W/ POWER TRANSISTOR)
IGNITION COIL 4 (W/ POWER TRANSISTOR)
IGNITION COIL 5 (W/ POWER TRANSISTOR)
IGNITION COIL 6 (W/ POWER TRANSISTOR)
INVERTER UNIT
LEFT FRONT COMBINATION LAMP
LEFT FRONT DOOR SATELLITE SENSOR SHIELD
LEFT FRONT SEAT HEATER
LEFT FRONT SIDE AIR BAG SATELLITE SENSOR (SHIELD)
LEFT POWER SEAT SWITCH
LEFT REAR SIDE AIR BAG SATELLITE SENSOR SHIELD
MOONROOF MOTOR ASSEMBLY
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT
RIGHT FRONT DOOR SATELLITE SENSOR SHIELD
RIGHT FRONT FOG LAMP
RIGHT FRONT FOG LAMP ASSEMBLY
RIGHT FRONT SIDE AIR BAG SATELLITE SENSOR (SHIELD)
RIGHT REAR SIDE AIR BAG SATELLITE SENSOR SHIELD
SHIELD
TRAILER TOW RELAY 1
TRAILER TOW RELAY 2
W/ FRONT HEATED SEATS
W/ LED HEADLAMPS
W/ MOONROOF
W/O LED HEADLAMPS
WASHER FLUID LEVEL SWITCH
Go to component -> Ground distribution circuit (2 of 6) -> CRASH ZONE SHIELD
