Nissan Frontier D41 (2021-2024) blind spot warning indicator Wiring diagram
This page shows the only wiring diagram for the component.blind spot warning indicator, which is found in the car Nissan Frontier D41 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blind spot warning indicator (1 of 1)
BLIND SPOT WARNING INDICATOR
BLK WIRE
BLU WIRE
BRN WIRE
CAMERA
DEFOGGER SYSTEM
DOOR MIRROR REMOTE CONTROL SWITCH
DOWN
FUSE 18
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
LEFT
LEFT DOOR MIRROR
LT BLU WIRE
MIRROR SWITCH
NAVIGATION SYSTEM
OFF
PNK WIRE
PPL/BLK WIRE
PPL/BLU WIRE
PPL/LT GRN WIRE
PPL/WHT WIRE
RED WIRE
RIGHT
RIGHT DOOR MIRROR
RIGHT END OF DASH)
SELECT SWITCH
SHIELD
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> BLIND SPOT WARNING INDICATOR
