4wd circuit, m/t for Nissan Frontier D40 (2004-2010)

BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) FUSE 14 FUSE 21 FUSE BLOCK (J/B) (UNDER RIGHT SIDE OF DASH) GND MEM B/U GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGN SW IGNITION SWITCH IND LOCK LOCK IND LT BLU WIRE LT GRN WIRE MTR - GND NEUT SW ORG/ WIRE PARK/ NEUTRAL POSITION SWITCH (ON TRANSMISSION) PNK WIRE RED WIRE RUN WIRE SSOF SWITCH TRANSFER CASE CONTROL UNIT (BEHIND LEFT SIDE OF DASH) UNIFIED METER CONTROL UNIT VIGN VIGN VIO WIRE WAIT DETECTION SWITCH (UNDER VEHICLE, NEAR TRANSFER CASE) WHT WIRE WHT/GRN WIRE YEL WIRE

ACTR SW 1 ACTR SW 2 ACTR SW 3 ACTR SW 4 BLK WIRE BLU WIRE BRN WIRE FUSE FUSE 57 FUSE 58 FUSE, FUSIBLE LINK BOX FUSE, RELAY BOX (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE ORG/ WIRE RED WIRE SHIFT SWITCH TRANSFER CONTROL DEVICE (ACTUATOR POSITION SWITCH) TRANSFER SHIFT HIGH RELAY TRANSFER SHIFT LOW RELAY TRANSFER SHUT OFF RELAY 1 TRANSFER SHUT OFF RELAY 2 VIO WIRE WHT WIRE WHT/GRN WIRE YEL WIRE
