Nissan Frontier D40 (2004-2010) w/ front map lamps Wiring diagram
This page shows the only wiring diagram for the component.w/ front map lamps, which is found in the car Nissan Frontier D40 (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ front map lamps (1 of 1)
4 2 PNK WIRE
47 48 50 DOOR SW (DR) DOOR SW (RL) CARGO LAMP OUTPUT PNK PNK WIRE
57 67 70 BAT (FUSE) GND BAT (F/L)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER OF DASH)
BRN WIRE
CARGO LAMP SWITCH
COMPUTER DATA LINES SYSTEM
CREW CAB
DIODE 6
FRONT ROOM/MAP LAMP ASSEMBLY (W/ FRONT MAP
FUSE 1
FUSE 18
FUSE 25
FUSE BLOCK (J/B) (UNDER RIGHT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK G
GRN WIRE
GRY WIRE
HIGH MOUNTED STOP LAMP (CARGO LAMP)
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEYHOLE ILLUMINATION
INSTRUMENT ILLUMINATION CIRCUIT
KEY SWITCH
KING CAB
LAMPS)
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (CREW CAB) (IN LEFT "C" PILLAR)
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH (CREW CAB)
ROOM LAMP
ROW
VIO WIRE
W/ FRONT MAP LAMPS
W/O FRONT MAP LAMPS
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, without power door locks -> W/ FRONT MAP LAMPS
