Nissan Frontier D40 (2004-2010) left sliding motor Wiring diagram
This page shows the only wiring diagram for the component.left sliding motor, which is found in the car Nissan Frontier D40 (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left sliding motor (1 of 1)
BLK WIRE
BLU WIRE
BWD
CIRCUIT BREAKER 2 (BEHIND LEFT END OF DASH)
DOWN
DWN
FRONT LIFTING SWITCH
FUSE, FUSIBLE LINK BOX (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK G
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT LIFTING MOTOR
LEFT POWER SEAT SWITCH
LEFT REAR LIFTING MOTOR
LEFT RECLINING MOTOR
LEFT SLIDING MOTOR
LT GRN WIRE
ORG/ WIRE
PNK WIRE
REAR LIFTING SWITCH
RECLINING SWITCH
RED WIRE
RIGHT POWER SEAT SWITCH
RIGHT RECLINING MOTOR FWD
RIGHT SLIDING MOTOR
SLIDING SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power seat circuit -> LEFT SLIDING MOTOR
