Nissan Frontier D40 (2004-2010) differntial lock control unit Wiring diagram
This page shows the only wiring diagram for the component.differntial lock control unit, which is found in the car Nissan Frontier D40 (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram differntial lock control unit (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DIFF LOCK IND
DIFF LOCK SW DIFF LOCK IND DIFF LOCK SW OFF
DIFF LOCK SW ON GND DIFF LOCK LOW DIFF LOCK HIGH SSS
DIFFERENTIAL LOCK MODE SWITCH
DIFFERENTIAL LOCK POSITION SWITCH (AT DIFFERENTIAL)
DIFFERENTIAL LOCK SOLENOID (AT DIFFERENTIAL)
DIFFERNTIAL LOCK CONTROL UNIT
FUSE 14 (UNDER RIGHT SIDE OF DASH)
FUSE 19
FUSE 3
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
PNK WIRE
RED WIRE
RED/YEL WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Differential lock circuit -> DIFFERNTIAL LOCK CONTROL UNIT
