Nissan Armada II (2016-2020) Computer data lines circuit, 4wd w/o icc

A/C AUTOMATIC AMPLIFIER (UPPER CENTER DASH) A/T ASSEMBLY (ON TRANSMISSION) ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) BCM (BODY CONTROL MODULE) (LEFT SIDE OF DASH) BLK WIRE BLU WIRE CAN L CAN-H CAN-H ENG COMM LINE CAN-H PNK CAN-L WIRE COMBINATION METER COMM COMM (H) COMM (L) DATA LINK CONNECTOR ECM (RIGHT REAR OF ENGINE COMPT) ENG COMM LINE FUSE 11 FUSE 3 FUSE 6 FUSE BLOCK (J/B) GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) JOINT CONNECTOR K LINE LOW TIRE PRESSURE WARNING CONTROL UNIT LT BLU WIRE NCA WIRE OCCUPANT DETECTION SYSTEM CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT) ORG/BLU WIRE PNK CAN-L WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE REAR A/C CONTROL RED/BLK WIRE RED/WHT WIRE RR CONT RX RR CONT TX STEERING ANGLE SENSOR (IN STEERING COLUMN) TCM (TRANSMISSION CONTROL MODULE) VVEL CONTROL MODULE WHT WIRE YAW RATE/SIDE/DECEL G SENSOR (UNDER REAR OF CENTER CONSOLE) YEL WIRE

AIR BAG DIAGNOSIS SENSOR UNIT AIR LEVELIZER CONTROL MODULE AROUND VIEW MONITOR CONTROL UNIT AUTOMATIC BACK DOOR CONTROL MODULE AV COMM (H) AV COMM (L) AV COMM SIG (H) AV COMM SIG (L) AV CONTROL UNIT (CENTER OF DASH) BLK WIRE BLU WIRE BLU/RED WIRE CAN L CAN-H CAN-H PNK CAN-L WIRE DIAG CAN H DIAG CAN L DISPLAY CONTROL UNIT DRIVER SEAT CONTROL UNIT (W/ MEMORY) DRIVER SIDE FRONT SEAT GRY WIRE IGN IT CAN-H IT CAN-L LT BLU WIRE LT GRN WIRE MULTI- FUNCTION SWITCH PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PPL RED WIRE RED/YEL WIRE SONAR CONTROL UNIT (LEFT SIDE OF DASH) TCU (RIGHT SIDE OF DASH) TRANSFER CONTROL UNIT (LOWER RIGHT SIDE OF DASH) VEHICLE CAN 1 H VEHICLE CAN 1 L VEHICLE CAN 2 H VEHICLE CAN 2 L VIDEO DISTRIBUTOR (CENTER OF DASH) W/ TELEMATICS W/O TELEMATICS YEL WIRE
