Nissan Armada II (2016-2020) right second seat Wiring diagram
This page shows the only wiring diagram for the component.right second seat, which is found in the car Nissan Armada II (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right second seat (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
FUSE 14
FUSE 15
FUSE BLOCK (J/B)
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
ILL
LEFT SEAT BACK HEATER
LEFT SEAT CUSHION HEATER
LEFT SECOND HEATED SEAT SWITCH
LEFT SECOND SEAT
LOW HIGH OFF
LOW OFF
MAIN HEATER
ORG/ WIRE
PPL
RED WIRE
RIGHT SEAT BACK HEATER
RIGHT SEAT CUSHION HEATER
RIGHT SECOND HEATED SEAT SWITCH
RIGHT SECOND SEAT
SUB HEATER
THERMOSTAT
WHT WIRE
Go to component -> Heated seats circuit (1 of 2) -> RIGHT SECOND SEAT
