Car Wiring Diagrams for Heated seats circuit for Nissan Armada I (2003-2007)

BLK WIRE BLU WIRE BRN WIRE FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) FUSE 16 GRN WIRE GRY WIRE HEATER HEATER THERMOSTAT HOT IN ON OR START ILLUM INTERIOR LIGHTS LEFT FRONT HEATED SEAT SWITCH LEFT FRONT SEAT HEATER LOW HIGH OFF LOW OFF ILLUM RED/BLU WIRE RIGHT FRONT HEATED SEAT SWITCH RIGHT FRONT SEAT HEATER SYSTEM
